Stainless Steel Air Curtain 1000RPM 16-20 m/s for Food Factory

Name: Stainless Steel Air Curtain 1000RPM 1620 ms for Food Factory
Brand: Theodoor or OEM
Price: 299 USD

Quality Stainless Steel Air Curtain 1000RPM 16-20 m/s for Food Factory for sale

Place of Origin : Guangdong, China

Brand Name : Theodoor or OEM

Model Number : FM-3509S-L, FM-4009S-L

MOQ : 50

Price : $299

Blade Material : Stainless Steel

Voltage : Customized

Speed : 1000RPM

Power Supply : AC 220-240V

Noise Level : 40db and above

Mounting Height : 3.5-4m

Size Width : 0.9m, 1m, 1.2m, 1.5m, 1.8m

Impeller Type : Dynamic Balanced ABS fan

Air Speed : 16 - 20 m/s

Input Power : 230W - 600W

Air Flow : 1100 - 2850 m3/h

Noise Level Hi : 52 - 61 dB

Noise Level Lo : 49 - 58 dB

Net Weight : 14 - 30 kg

Casing Material : Stainless Steel

Contact Now

High Performance Theodoor Air Curtain , Stainless Steel Air Curtain 16 - 20 m/s

Product Description

Feature:

Stainless steel cabinet design won’t be rusty and discoloration;

High grade with elegant appearance;

Adopting high-performance motor, safe and reliable; Centrifugal turbine creates higher air velocity;

Adopting updated remote control with high and low speeds operation;

Suitable for installation in luxury hotel, supermarket chains, large stadiums and airport terminals and other

entrances of high-grade places etc;

Stainless steel cover design air curtain; Centrifugal type air flow produce high air speed; Steady and

effective performance.

Stainless Steel Air Curtain Specifications:

1) Switch
2) Two speeds
3) Stainless steel cover
4) Centrifugal type air flow
5) Applications: 3-4m doors
6) Available size: 900mm, 1,000mm, 1,200mm, 1,500mm, 1,800mm

Specifications:

Model	Size (mm)	Volt./ Freq.	Input power(W)		Air flow (m3/h)		Air speed (m/s)	Noise (dB)		N.W (kg)
Model	Size (mm)	Volt./ Freq.	Hi	Lo	Hi	Lo	Air speed (m/s)	Hi	Lo	N.W (kg)
FM-3509S-L	900x215x240	220v/50Hz	230	200	1100	900	13-16	52	49	14
FM-3510S-L	1000x215x240		250	220	1200	1000		52	49	15
FM-3512S-L	1200x215x240		290	260	1500	1200		53	50	18.5
FM-3515S-L	1500x215x240		380	350	1900	1500		55	52	25
FM-3518S-L	1800x215x240		450	420	2200	1800		57	54	30
FM-4009S-L	900x215x240	220v/50Hz	300	270	1400	1000	16-20	57	54	14
FM-4010S-L	1000x215x240		320	290	1550	1100		57	54	15
FM-4012S-L	1200x215x240		400	370	1900	1500		57	55	18.5
FM-4015S-L	1500x215x240		500	470	2300	1900		58	55	25
FM-4018S-L	1800x215x240		600	570	2850	2250		61	58	30
