Stainless Steel Elevator Air Curtain 80W with Induction Sensor
Premium Products
Stainless Steel Elevator Air Curtain 80W with Induction Sensor
1
2
3
4
5
6
Place of Origin :Guangdong, China
Brand Name :Theodoor
MOQ :1
Price :$89-99
Blade material :Plastic
Mounting type :Wall Fan
Voltage :230V
Fan type :Cross flow fan
Body material :Stainless steel or steel
Fan speed :1-speed
Air velocity :7.5m/s
Power :80W
Dimension :800x142x172mm
Input power :80W
Air volume :650m3/h
Noise level :49db
Net weight :5Kg
Color :White or Stainless steel
Motor type :Pure copper silicon steel sheet
Contact Now
Elevator ventilating air curtain fan for residential and commercial places.
Product Description
Features:
Stainless steel body
Stainless steel body integrated with the elevator environment, strong and durable, no rust, clean as new.
Double-sided air inlet design, can be installed in the highest point of the elevator, handling large luggage is not affected.
Air outlet protective net design, Safety structure to avoid fingers reach inside.
Induction sensor
Human body sensing, intelligent switch. When people enter the elevator, automatic start; People leave, automatic shutdown, can be set delay shutdown, energy saving.
High performance
Using pure copper silicon steel sheet motor, the experimental test has been running for more than 8000 hours without fault. High quality ball bearing wind wheel, stable and durable and energy saving.
High air volume
Golden Angle air supply design, body feeling more comfortable, high air volume and low noise. Solves the problem that the ordinary air curtain machine blows straight to the ground and is not cool enough.
Specification:
Model
Dimension (mm)
Voltage (V)
Input power
(W)
Air Volume
(m3/h)
Air
Speed
(m/s)
Noise
(db)
Net Weight
(Kg)
Color
FM-1008DT
(Manual switch)
800x142x172
220V
80
650
7.5
49
5
White
FM-1008DT
(Sensor)
800x142x172
80
650
49
5
White
FM-1008DT
(Stainless steel and sensor)
800x142x172
80
650
49
5
Stainless steel
Packaging & Shipping
Our Services
OEM, ODM
Label, box design
Shipping arrangement
After sales spare parts support
Company Information
FAQ
How to select suitable air curtain?
There are many factors that we have to consider when selecting an air curtain, some of which are listed below: 1. Application 2. Door height 3. Door width 4. Outside wind 5. Building static pressure 6. Door structure 7. Ambient temperature 8. Air curtain size 9. Air curtain design and look 10. Noise level
