4G Series Air Curtain 900-2000mm 220-240V Low Noise Compact
Premium Products
4G Series Air Curtain 900-2000mm 220-240V Low Noise Compact
1
2
3
4
5
6
Place of Origin :Guangdong, China
Brand Name :Theodoor
Certification :ISO 9001, ISO14001, CCC, CE
MOQ :100
Price :$99
Mounting Type :Wall / Window Mount
Weight :15 kg
Fan Motors Type :AC
Fan Type :Cross flow air door curtain
Power Supply :220-240V/1Ph/50Hz
Fan Speed :2-speed
Control :Remote control & switch
Voltage/Frequency :220-240v/50hz
Size :900x195x230 to 2000x195x230 mm
Length :900 to 2000 mm
Air Speed :11 m/s
Air Volume :1400 to 3600 m3/h
Noise Level :55 to 59 dB
Power :160 to 350 W
Net Weight :10.5 to 22.5 kg
Contact Now
Product Description
Feature
1.Elegant&Delicate appearance
Full stainless steel shell, and the super thin body won't rusty.
2.Stable performance
The high efficient motor, with overheating protector and has safety operation of 5000 hours continuously without defect.
3.Low noise operation
The optimized fan wheel provides stable & even air flow. It has large air volume and low noise performance.
4.Easy operation
Adopting remote control or key switch, it’s able to adjust high and low air velocity.
5.Application:for installation in hotel,chain supermarket,cafeteria, bakery, waiting room, restaurants, retail shop, department store, sports center etc.
Tech Spec
Item
Voltage/frequency (v/hz)
Size(mm)
Length
(mm)
Air speed
(m/s)
Air volume
(m3/h)
Noise
(dB)
Power
(w)
Net weight
FM-1209S2
220-240v/50hz
900x195x230
900
11
1400
55
160
10.5
FM-1210S2
220-240v/50hz
1000x195x230
1000
11
1600
56
180
11
FM-1212S2
220-240v/50hz
1200x195x230
1200
11
1900
56
190
13.5
FM-1215S2
220-240v/50hz
1500x195x230
1500
11
2500
57
230
16.5
FM-1218S2
220-240v/50hz
1800x195x230
1800
11
3200
58
300
19.5
FM-1220S2
220-240v/50hz
2000x195x230
2000
11
3600
59
350
22.5
Functions of Air Curtain:
Theodoor Air curtain is installed above the entryway of store, restaurant, hotel...etc. It can effectively isolate convection indoor and outdoor and keep temperature and humidity. Especially used in the location with air conditioner to keep indoor environment and save energy of refrigeration equipment. In addition, Air Curtain can prevent the invasion of dust, pest and harmful fumes from outside. In this way, a comfortable indoor climate is maintained.
